exdqlm — Extended Dynamic Quantile Linear Models

R-CMD-check

exdqlm is a Bayesian quantile-regression package that combines dynamic state-space quantile models with static extended asymmetric Laplace (exAL) regression through a common application programming interface (API). It is built for problems where quantiles, rather than means, are the main object of interest, but the user still wants familiar state-space/model-matrix inputs and explicit posterior inference.

The current release provides:

The package collects Bayesian dynamic quantile state-space modeling, static Bayesian quantile regression, multiple inference engines, shrinkage priors for static coefficients, and post hoc synthesis across quantiles in one interface.

Terminology. The exAL family generalizes the standard AL by adding a skewness parameter, allowing for asymmetric tails. The standard AL is a special case with zero skewness. We refer to the generalized AL from Kotz et al. as Kotz-GAL to avoid confusion.

Installation

CRAN (when available):

install.packages("exdqlm")

Development (GitHub):

# install.packages("pak")
pak::pak("AntonioAPDL/exdqlm")

Why exdqlm is distinctive

Workflow map

Goal Main functions Inference engines Notes
Dynamic quantile state-space model exdqlmLDVB(), exdqlmMCMC(), exdqlmISVB() LDVB, MCMC, legacy ISVB Main entry point for univariate time-series quantile modeling
Build state-space components polytrendMod(), seasMod(), regMod() n/a Compose trend, seasonal, and regression blocks with +.exdqlm
Dynamic fit examination plot(), predict(), diagnostics() post-fit summary Dynamic fits support standard plotting, forecasting, and diagnostics methods; forecast objects can also be scored with diagnostics(forecast, y = ...)
Static Bayesian exAL regression exalStaticLDVB(), exalStaticMCMC() LDVB, MCMC Supports al.ind = TRUE (alias of dqlm.ind = TRUE), posterior draws from either engine, and ridge, rhs, rhs_ns priors
Static fit diagnostics plot(), diagnostics() post-fit summary Static fits support fitted-quantile plots and diagnostic objects; use plot(diagnostic_object, type = "coefficients") for coefficient intervals
Static regression block inside a dynamic model regMod() n/a Adds fixed coefficients as a state-space component
Combine several separately fitted quantiles quantileSynthesis() post hoc synthesis Builds a unified posterior predictive distribution using isotonic correction and optional rearrangement

Object system

exdqlm uses ordinary S3 classes for fitted models and post-processing objects. Dynamic fits keep their engine-specific first class (exdqlmLDVB, exdqlmMCMC, or legacy exdqlmISVB) and also inherit from the shared exdqlmFit family. Static fits similarly inherit from exalStaticFit. Diagnostic, forecast, synthesis, and static-diagnostic functions return explicit objects with print(), summary(), and plot() methods where appropriate. Dynamic fits also support predict() for forecasting, and fitted/forecast/static objects support diagnostics() where diagnostic summaries are defined. Named helpers such as exdqlmPlot(), compPlot(), exdqlmForecast(), exdqlmDiagnostics(), exdqlmForecastDiagnostics(), and exalStaticDiagnostics() remain available for explicit or backward-compatible workflows.

Which engine should I use?

Setting Recommended start Use when Alternatives
Dynamic exDQLM exdqlmLDVB() You want the standard variational fit for dynamic exDQLM exdqlmMCMC() or legacy exdqlmISVB()
Dynamic exDQLM with posterior sampling exdqlmMCMC() You want retained posterior draws and full simulation-based summaries warm-start from VB if needed
Legacy dynamic exDQLM VB exdqlmISVB() You need backward-compatible behavior or historical comparisons exdqlmLDVB()
Static exAL regression exalStaticLDVB() You want a fast Bayesian approximation, often useful before MCMC exalStaticMCMC()
Static exAL regression with posterior draws exalStaticLDVB() or exalStaticMCMC() Use exalStaticLDVB() for a fast approximate draw-based summary and exalStaticMCMC() for the simulation baseline init.from.vb = TRUE can help the MCMC fit

Default warmup behavior

The package now applies a conservative automatic warmup profile for the most numerically delicate shared blocks, so ordinary users do not have to assemble nested warmup lists just to get a stable first fit.

In practice, the recommended workflow is:

  1. fit the model with the default API;
  2. inspect diagnostics if the fit still looks unstable;
  3. only then override the warmup controls explicitly.

Quick start (≤ 10 lines)

Local-level model at a single quantile (the median) using the package’s main dynamic VB engine. We keep the pure-R path for CRAN-style reproducibility and use the reduced DQLM path to keep the example small.

set.seed(1)
library(exdqlm)

T      <- 120
state  <- cumsum(rnorm(T, sd = 0.2))
y      <- state + rnorm(T, sd = 1.0)

model  <- list(FF = matrix(1), GG = matrix(1), m0 = 0, C0 = 100)
options(exdqlm.use_cpp_kf = FALSE, exdqlm.use_cpp_samplers = FALSE)

fit <- exdqlmLDVB(
  y = y, p0 = 0.5, model = model, df = 0.98, dim.df = 1,
  dqlm.ind = TRUE, sig.init = 1.0
)

tail(fit$diagnostics$elbo, 3)

For plotting or monitoring VB convergence, use the standardized trace table:

head(fit$diagnostics$vb_trace[, c("iter", "elbo", "sigma", "gamma")])

Core concepts (at a glance)

Current release highlights

For CI/CRAN-style runs, keep optional C++ builders/samplers/post-pred FALSE and set exdqlm.use_cpp_kf = FALSE for strict R-path reproducibility.

Runtime options (summary)

Option Default Effect Use when…
exdqlm.use_cpp_kf TRUE C++ Kalman filter bridge you have compilers/OpenMP and want speed
exdqlm.use_cpp_builders FALSE C++ matrix builders (polytrendMod, seasMod) opt-in parity-tested builder speedups
exdqlm.use_cpp_samplers FALSE C++ samplers for posterior draws same as above; keep OFF on CRAN/examples
exdqlm.use_cpp_postpred FALSE C++ posterior predictive sampler optional speed path after parity checks
exdqlm.use_cpp_mcmc TRUE MCMC backend routing C++ forward-filtering backward-sampling (FFBS) by default for MCMC
exdqlm.cpp_mcmc_mode fast MCMC mode (strict/fast) strict parity checks or fast C++ FFBS

Set with:

options(exdqlm.use_cpp_kf = TRUE)
options(exdqlm.use_cpp_builders = FALSE)
options(exdqlm.use_cpp_samplers = TRUE)
options(exdqlm.use_cpp_postpred = FALSE)
options(exdqlm.use_cpp_mcmc = TRUE)
options(exdqlm.cpp_mcmc_mode = "fast")

Backend control (minimal): - Force pure-R backend: set options(exdqlm.use_cpp_kf = FALSE, exdqlm.use_cpp_builders = FALSE). - Keep builder calls explicit with backend = "R" or backend = "cpp" in polytrendMod() and seasMod().

Minimal examples (CRAN-safe)

1) Single-quantile fit on built-in data (tiny slice)

Trend + seasonality + one climate-index regressor. Note: FF for the regressor is 1 × T. Combine components pairwise.

data("BTflow", package = "exdqlm")
data("climateIndices", package = "exdqlm")

set.seed(2)
T <- 150
y <- log(BTflow[seq_len(T)])
bt_dates <- seq(as.Date("1987-01-01"), by = "month", length.out = T)
idx <- match(bt_dates, climateIndices$date)
x <- scale(climateIndices$noi[idx])[, 1]

trend.comp <- polytrendMod(order = 1, m0 = 0, C0 = 1)
seas.comp  <- seasMod(p = 12, h = 1, C0 = diag(1, 2))

# 1-d regressor block (explicit 1 x T design)
reg.comp <- list(m0 = 0, C0 = 1, FF = matrix(x, nrow = 1), GG = matrix(1))

# combine via +.exdqlm
reg.comp <- as.exdqlm(reg.comp)
model    <- trend.comp + seas.comp + reg.comp

# one discount per block: (trend, seasonal[2-d], reg)
df     <- c(1.00, 0.98, 1.00)
dim.df <- c(1,       2,   1)

options(exdqlm.use_cpp_kf = FALSE, exdqlm.use_cpp_samplers = FALSE)

fit <- exdqlmLDVB(
  y = y, p0 = 0.5, model = model,
  df = df, dim.df = dim.df,
  dqlm.ind = TRUE, sig.init = 0.2
)

# quick checks
tail(fit$diagnostics$elbo, 2)
dim(fit$theta.out$sm)  # state-dimension x time

2) exAL helper sanity check (CDF ↔︎ quantile)

set.seed(3)
x      <- seq(-2, 2, length.out = 5)
p0     <- 0.25
mu     <- 0
sigma  <- 1
gamma  <- 0.0

# CDF then invert with QF — should approximately return x
cdf_vals <- pexal(x,  p0 = p0, mu = mu, sigma = sigma, gamma = gamma)
x_back   <- qexal(cdf_vals, p0 = p0, mu = mu, sigma = sigma, gamma = gamma)

round(cbind(x, x_back), 4)
#>       x x_back
#> [1,] -2     -2
#> [2,] -1     -1
#> [3,]  0      0
#> [4,]  1      1
#> [5,]  2      2

# A few random draws
rexal(5, p0 = p0, mu = mu, sigma = sigma, gamma = gamma)
#> [1] -0.5296664  5.4402490  0.7934288  0.4376783  2.5354967

CRAN-safety. All examples set a seed, use tiny data, finish in a few seconds, and explicitly keep the pure-R path.

3) Static Bayesian regression with reduced AL and RHS-family priors

set.seed(4)
n <- 80
p <- 5
X <- matrix(rnorm(n * p), n, p)
beta <- c(1, -1, 0, 0, 0.5)
y <- as.numeric(X %*% beta + rnorm(n))

# Reduced AL fit (gamma fixed at zero)
fit_al <- exalStaticLDVB(
  y = y, X = X, p0 = 0.5,
  al.ind = TRUE,
  max_iter = 150, tol = 1e-4, verbose = FALSE
)

# exAL fit with regularized horseshoe prior on coefficients
fit_rhs <- exalStaticMCMC(
  y = y, X = X, p0 = 0.5,
  beta_prior = "rhs",
  n.burn = 200, n.mcmc = 200, thin = 1,
  mh.proposal = "slice",
  trace.diagnostics = FALSE,
  verbose = FALSE
)

# exAL fit with rhs_ns controls (same API family, additive option)
fit_rhs_ns <- exalStaticMCMC(
  y = y, X = X, p0 = 0.5,
  beta_prior = "rhs_ns",
  beta_prior_controls = list(
    tau0 = 0.5,
    a_zeta = 2,
    b_zeta = 1,
    shrink_intercept = FALSE
  ),
  n.burn = 200, n.mcmc = 200, thin = 1,
  mh.proposal = "slice",
  trace.diagnostics = FALSE,
  verbose = FALSE
)

fit_al$dqlm.ind
fit_rhs$beta_prior$type
fit_rhs_ns$beta_prior$type

4) Multi-quantile synthesis (conceptual sketch)

Fit several quantiles separately, then combine their posterior predictive draws into a single unified posterior predictive distribution.

p_grid <- c(0.1, 0.5, 0.9)
fits <- lapply(p_grid, function(tau) {
  exdqlmLDVB(
    y = y, p0 = tau, model = model,
    df = df, dim.df = dim.df,
    sig.init = 0.2, gam.init = 0
  )
})

draws <- lapply(fits, function(m) m$samp.post.pred)

syn <- quantileSynthesis(
  draws_list = draws,
  p = p_grid,
  T_expected = length(y)
)

names(syn)

FAQ / Troubleshooting

How to cite

Barata, R., Prado, R., & Sansó, B. (2022). Fast inference for time-varying quantiles via flexible dynamic models with application to the characterization of atmospheric rivers. Annals of Applied Statistics, 16(1), 247–271. https://doi.org/10.1214/21-AOAS1497

License

MIT © The authors. See LICENSE.

Getting help

Open an issue: https://github.com/AntonioAPDL/exdqlm/issues
